PCIexpress-KiCad

PCI Express™ libraries and templates for KiCad Made using guidelines from PCI Express™ Card Electromechanical Specification Rev. 1.1

Contents

Templates:

• x1 cards: full size, half length, low profile
• x4 cards: full size, half length, low profile
• x8 cards: full size, half length, low profile
• x16 cards: full size, half length, low profile

Symbols:

• x1
• x4
• x8
• x16
• Bracket

Footprints:

• x1 with multiple card outlines
• x4 with multiple card outlines
• x8 with multiple card outlines
• x16 with multiple card outlines
• Full height bracket (with 3D model)
• Low profile bracket (with 3D model)
• Low profile to full height adapter bracker (with 3D model)

###License This documentation describes Open Hardware and is licensed under the CERN OHL v.1.2.

You may redistribute and modify this documentation under the terms of the CERN OHL v.1.2. (http://ohwr.org/cernohl). This documentation is distributed WITHOUT ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING OF MERCHANTABILITY, SATISFACTORY QUALITY AND FITNESS FOR A PARTICULAR PURPOSE. Please see the CERN OHL v.1.2 for applicable conditions.
